A vertical windlass that is suitable for boats ranging from 7-12 metres (23-40ft). The vertical anchor windlass has an integrated sensor and magnet for chain counter, as well as a manual free-fall system.

In addition, the Quick windlass features a 8mm (5/6") gypsy, which is suitable for 8mm ISO chain and a 1/2" rope. This is the kit version of the 1000, which includes a contractor unit, nylon handle, foot switch and a hydraulic magnetic circuit breaker.

Specifications:

Boat Size: 7-12 metres in length.
Gypsy Size: 8mm.
Voltage: 12V DC.
Wattage: Motor Power 800W.
Working Load: 95kg.
Working Load (Maximum): 290kg.
Pull Load (Maximum): 820kg.
Chain Speed (Maximum): 22.5 metres per minute.
Chain Speed At Working Load (Maximum): 15.2 metres per minute.
Current Absorption At Working Load: 84A.
Fuse: 80A protection circuit breaker.
Height: 287.5mm.
Width: 196mm.
Depth: 145.4mm.
Size: Motor Cable 25mm2 (AWG3).

Contents:
Contactor Units, Nylon Handle, Foot Switch, Hydraulic Magnetic Circuit Breaker, Drilling Template, User Manual.
