An AISI 316 stainless steel lag screw eye that is an economical alternative to a fully forged shackle.
Technical Specifications:
Please refer to the diagram in the product images.
5mm x 35mm | 5mm x 50mm | 6mm x 60mm | 8mm x 60mm | 8mm x 100mm | |
Dia (mm) | 5 | 5 | 6 | 8 | 8 |
A (mm) | 35 | 50 | 60 | 100 | 60 |
B (mm) | 20 | 30 | 36 | 60 | 36 |
C (mm) | 11 | 11 | 11 | 18 | 18 |
